Electronic Instrumentation Cables

Color coded multi-conductor, pair and triad cables

Electronic and Instrumentation Cable describes a 300V multi-conductor, multi-paired or multi-triad cable used for low voltage signal transmission and monitoring of machinery and equipment critical to the production process. This type of cable is typically available in sizes 22AWG to 12AWG with color coded conductors, overall shielded and/or individually shielded and unshielded in both flexible and continuous flexing constructions. Approvals can range from UL Listed Power Limited Tray Cable (PLTC), Communication (type CM), Instrumentation Tray Cable (ITC) or UL recognized as Appliance Wiring Material (AWM).

Types

Flexible MULTI-CONDUCTOR Series UNSHIELDED

LUTZE ELECTRONIC PLTC A303

  • Jacket: PVC, gray

  • Insulation: SR-PVC, color coded

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL PLTC 105°C, AWM

  • Range: AWG 22 -16;  up to 25 conductors

  • Spec Sheet

LAPP UNITRONIC® 300

  • Jacket: PVC, gray

  • Insulation: special PVC, color coded

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL CMG, PLTC, PLTC-ER, ITC-ER, AWM

  • Range: AWG 24 -16;  up to 25 conductors

  • Spec Sheet

HELUKABEL TRAYCONTROL® 300

  • Jacket: PVC, gray

  • Insulation: special PVC, color coded

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL PLTC-ER, ITC-ER, AWM 2517, CM; CSA

  • Range: AWG 28 -16;  up to 50 conductors

  • Spec Sheet

SAB DC 105 PLTC

  • Jacket: PVC, gray

  • Insulation: semi-rigid PVC (AWG26-20), color coded

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL PLTC, PLTC-ER, ITC-ER, CMG;  CSA, CE

  • Range: AWG 26 -16;  up to 50 conductors

  • Spec Sheet

ALPHA Xtra-Guard® 1 Multiconductor

  • Jacket: PVC, gray

  • Insulation: PVC, color coded

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL AWM, CM, MTW, CSA

  • Range: AWG 28 -16;  up to 50 conductors

  • Spec Sheet

ALPHA Xtra-Guard® 2 Multiconductor

  • Jacket: PUR, black

  • Insulation: PVC, color coded

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL AWM, CSA

  • Range: AWG 24 -16;  up to 70 conductors

  • Spec Sheet

BELDEN MACHFLEX® 360TC CONTROL

  • Jacket: TPE, gray

  • Insulation: PVC, black and numbered

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL PLTC, AWM; CSA, CE

  • Range: AWG 20;  up to 24 conductors

  • Spec Sheet

ALPHA Series P PLTC TPE

  • Jacket: TPE, gray

  • Insulation: PVC/Nylon, black and numbered

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL PLTC, CSA, CE

  • Range: AWG 18 -12;  up to 65 conductors

  • Spec Sheet

Flexible MULTI-CONDUCTOR Series SHIELDED

LUTZE Electronic PVC, A313

  • Jacket: PVC, gray

  • Insulation: SR-PVC, color coded

  • Shielding: Foil, Braid, Drain wire

  • Voltage: 300V

  • Certifications: UL PLTC, AWM 2464

  • Range: AWG 22 -16;  up to 25 conductors

  • Spec Sheet

LAPP UNITRONIC® 300 S

  • Jacket: PVC, gray

  • Insulation: special PVC, color coded

  • Shielding: Foil, Braid

  • Voltage: 300V

  • Certifications: UL CMG, PLTC, PLTC-ER, ITC-ER, AWM

  • Range: AWG 24 -16;  up to 25 conductors

  • Spec Sheet

HELUKABEL TRAYCONTROL® 300-C

  • Jacket: PVC, gray

  • Insulation: special PVC, color coded

  • Shielding: Foil, Braid

  • Voltage: 300V

  • Certifications: UL PLTC-ER, ITC-ER, AWM 2517, CM;  CSA

  • Range: AWG 28 -16;  up to 50 conductors

  • Spec Sheet

SAB DC 105 PLTC

  • Jacket: PVC, gray

  • Insulation: semi-rigid PVC (AWG26-20), color coded

  • Shielding: Foil, Braid, Drain Wire

  • Voltage: 300V

  • Certifications: UL PLTC (22-20AWG), PLTC-ER, ITC-ER (18-16AWG), CMG;  CSA, CE

  • Range: AWG 26 -16;  up to 50 conductors

  • Spec Sheet

BELDEN MACHFLEX® SUPER 360TC

  • Jacket: TPE, gray

  • Insulation: PVC, black and numbered

  • Shielding: Shielded

  • Voltage: 300V

  • Certifications: UL PLTC, AWM; CSA, CE

  • Range: AWG 20;  up to 25 conductors

  • Spec Sheet

ALPHA Xtra-Guard® 1 Supra-Shield®

  • Jacket: PVC, gray

  • Insulation: PVC, color coded

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL AWM, CM, MTW, CSA

  • Range: AWG 28 -16;  up to 50 conductors

  • Spec Sheet

Flexible MULTI-PAIR Series UNSHIELDED

BELDEN UL INSTRUMENTATION PLTC

  • Jacket: PVC, gray

  • Insulation: PVC, color coded

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL PLTC, ITC, AWM 2464, CMG; CE

  • Range: AWG 22 – 16;  1 pair

  • Spec Sheet

ALPHA Xtra-Guard® 1 Multipair PVC

  • Jacket: PVC, gray

  • Insulation: PVC, color coded

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL AWM, CM, CSA

  • Range: AWG 24 -18;  up to 15 pairs

  • Spec Sheet

BELDEN UL INSTRUMENTATION, PAIRS

  • Jacket: PVC, gray

  • Insulation: PVC, color coded

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL AWM, CMG

  • Range: AWG 24 – 20;  up to 27 pairs

  • Spec Sheet

Flexible MULTI-PAIR Series SHIELDED

LUTZE Electronic, PAIRS

  • Jacket: PVC, gray

  • Insulation: SR-PVC, color coded

  • Shielding: Foil, Braid, Drain wire

  • Voltage: 300V

  • Certifications: UL PLTC, AWM 2464

  • Range: AWG 22 – 16; up to 8 pairs

  • Spec Sheet

SAB DC 105 TP, PAIRS

  • Jacket: PVC, gray

  • Insulation: semi-rigid PVC (AWG24-20), color coded

  • Shielding: Foil, Braid, Drain Wire

  • Voltage: 300V

  • Certifications: UL PLTC (22-20AWG), PLTC-ER, ITC-ER (18-16AWG), CMG;  CSA, CE

  • Range: AWG 24 -16;  up to 15 pairs

  • Spec Sheet

LAPP UNITRONIC® 300 STP

  • Jacket: PVC, gray

  • Insulation: special PVC, color coded

  • Shielding: Foil, Braid

  • Voltage: 300V

  • Certifications: UL PLTC-ER, ITC-ER, CMG, AWM 2464; CSA, CE

  • Range: AWG 24 -16;  up to 15 pairs

  • Spec Sheet

BELDEN UL INSTRUMENTATION, PAIRS

  • Jacket: PVC, gray

  • Insulation: PVC, color coded

  • Shielding: TSP and/or Overall shield

  • Voltage: 300V

  • Certifications: UL PLTC, ITC, AWM 2464, CMG; CE

  • Range: AWG 22 – 16;  1 pair

  • Spec Sheet

ADC TYPE PLTC PAIRS

  • Jacket: PVC, black

  • Insulation: PVC, color coded (black/white)

  • Shielding: overall shielded

  • Voltage: 300V

  • Certifications: UL PLTC, ITC

  • Range: AWG 20 – 16;  up to 16 pairs

  • Spec Sheet

ADC TYPE PLTC SHIELDED PAIRS

  • Jacket: PVC, black

  • Insulation: PVC, color coded (black/white)

  • Shielding: TSP + Overall shield

  • Voltage: 300V

  • Certifications: UL PLTC, ITC

  • Range: AWG 20 – 16;  up to 16 pairs

  • Spec Sheet

BELDEN UL INSTRUMENTATION SHIELDED PAIRS + OVERALL

  • Jacket: PVC, gray

  • Insulation: PVC, color coded

  • Shielding: TSP + Overall shield

  • Voltage: 300V

  • Certifications: UL PLTC, ITC

  • Range: AWG 22 – 16;  up to 19 pairs

  • Spec Sheet

ALPHA Xtra-Guard® 1 Multipair PVC

  • Jacket: PVC, gray

  • Insulation: PVC, color coded

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL AWM, CM, CSA

  • Range: AWG 28 -18;  up to 51 pairs

  • Spec Sheet

Flexible MULTI-TRIAD Series UNSHIELDED

BELDEN UL 300V PLTC, TRIADS

  • Jacket: PVC, gray

  • Insulation: PVC, color coded

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL PLTC, ITC, AWM, CMG; CE

  • Range: AWG 22 – 16;  1 triad

  • Spec Sheet

Flexible MULTI-TRIAD Series SHIELDED

BELDEN UL 300V PLTC, TRIADS

  • Jacket: PVC, black

  • Insulation: PVC, color coded

  • Shielding: TSP and/or overall foil shield

  • Voltage: 300V

  • Certifications: UL PLTC, ITC, AWM, CMG; CE

  • Range: AWG 22 – 16;  up to 36 triads

  • Spec Sheet

ADC TYPE PLTC TRIADS

  • Jacket: PVC, black

  • Insulation: PVC, color coded (black/white)

  • Shielding: TSP + overall foil shield + drain wire

  • Voltage: 300V

  • Certifications: UL PLTC, ITC

  • Range: AWG 20 – 16;  up to 16 pairs

  • Spec Sheet

High Flex MULTI-CONDUCTOR Series UNSHIELDED

BELDEN MACHFLEX® SUPER 360TC

  • Jacket: TPE, orange

  • Insulation: PVC, black and numbered

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL PLTC, AWM; CE

  • Range: AWG 20 – 16;  up to 24 conductor

  • Spec Sheet

LUTZE SUPERFLEX® TRONIC PUR

  • Jacket: PUR, gray

  • Insulation: TPE insulation, color coded

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL AWM 20549

  • Range: AWG 24-22;  up to 25 conductors

  • Spec Sheet

SAB SD 960 P

  • Jacket: PUR, gray

  • Insulation: PVC, color coded

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL AWM, CSA, CE

  • Range: AWG 26 -22;  up to 25 conductors

  • Spec Sheet

ALPHA Xtra-Guard® Continuous Flex Data

  • Jacket: PVC, gray

  • Insulation: PVC, color coded

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL AWM, CM, CSA

  • Range: AWG 28 -22;  up to 25 conductors

  • Spec Sheet

LUTZE SUPERFLEX® TRONIC AS PUR

  • Jacket: PUR, black

  • Insulation: TPE, color coded

  • Shielding: Unshielded

  • Voltage: 300V

  • Certifications: UL AWM 20549

  • Range: AWG 22;  up to 18 conductors

  • Spec Sheet

High Flex MULTI-CONDUCTOR Series SHIELDED

LUTZE SUPERFLEX® TRONIC PUR

  • Jacket: PUR, matte gray

  • Insulation: TPE, DIN 47100 color code

  • Shielding: tinned copper braid

  • Voltage: 300V

  • Certifications: UL AWM

  • Range: AWG 26 – 22;  up to 25 conductors

  • Spec Sheet

LUTZE SUPERFLEX® TRONIC AS PUR

  • Jacket: PUR, black

  • Insulation: TPE, color code per EN 60947-5-2

  • Shielding: tinned copper braid

  • Voltage: 300V

  • Certifications: UL AWM

  • Range: AWG 22;  up to 5 conductors

  • Spec Sheet

BELDEN MACHFLEX® SUPER 360TC, PLTC

  • Jacket: TPE, orange

  • Insulation: PVC, black and numbered

  • Shielding: tinned copper braid

  • Voltage: 300V

  • Certifications: UL PLTC, AWM; CE

  • Range: AWG 20 – 16;  up to 24 conductor

  • Spec Sheet

High Flex MULTI-PAIR Series SHIELDED

LUTZE SUPERFLEX® TRONIC PUR TP

  • Jacket: PUR, gray

  • Insulation: TPE, DIN 47100 color code

  • Shielding: tinned copper braid

  • Voltage: 300V UL AWM

  • Certifications: UL AWM 20549, CE

  • Range: AWG 24 -19;  up to 12 pairs

  • Spec Sheet

ELETTROTEK FLEXIDRUM® 210 C TP

  • Jacket: PUR, gray

  • Insulation: TPE, DIN 47100 color code

  • Shielding: tinned copper braid

  • Voltage: 300V

  • Certifications: UL AWM 21198, CSA

  • Range: AWG 26 -16;  up to 25 pairs

  • Spec Sheet

SAB SD 960 CY TP

  • Jacket: PVC, black

  • Insulation: PVC, color coded

  • Shielding: braid shield

  • Voltage: 300V

  • Certifications: UL AWM; CE

  • Range: AWG 26 -20;  up to 25 pairs

  • Spec Sheet

SAB SD 960 CP TP

  • Jacket: PUR, gray

  • Insulation: PVC, color coded

  • Shielding: foil + braid shield + drain wire

  • Voltage: 300V

  • Certifications: UL AWM, CSA, CE

  • Range: AWG 26 -19;  up to 25 pairs

  • Spec Sheet

IGUS CHAINFLEX® CF211

  • Jacket: PVC, gray

  • Insulation: TPE, color coded

  • Shielding: tinned copper braid

  • Voltage: 300V

  • Certifications: UL AWM, CE

  • Range: AWG 24 -20;  up to 14 pairs

  • Spec Sheet

ALPHA Xtra-Guard® Continuous Flex Data

  • Jacket: PVC, gray

  • Insulation: PVC, color coded

  • Shielding: foil + braid shield

  • Voltage: 300V

  • Certifications: UL AWM, CM, CSA

  • Range: AWG 28 -22;  up to 25 conductors

  • Spec Sheet

Thermocouple Cables

BELDEN THERMOCOUPLE EXTENSION

  • Jacket: PVC or FEP

  • Insulation: PVC or FEP, color coded

  • Shielding: unshielded

  • Temp: 105°C – 200°C

  • Certifications: UL PLTC, ITC, CMG

  • Range: AWG 20 – 16;  up to 8 pairs

  • Spec Sheet
